Place of Origin: China Brand Name: KNOFC or OEM Certification: CE/ISO9001 Model Number: Fiber Optic Patch Panel 12 Ports Minimum Order Quantity: 1pcs Price: Negotiable Packaging Details: carton Supply Ability: 50000pcs/month
Description:
Optical splitter closure provides space and protection for the fiber optic cable splicing and joint.Fiber optic closure belongs to the accommodation of the optical fiber fusion splice section system. It is widely applied to the connection of the fiber play the roles in sealing, protection, installation of fiber connector head and storage.
Features:
1). High quality PC, ABS, PPR material optional, can ensure harsh conditions such as vibration, impact, tensile cable distortion
and strong temperature changes.
2). Solid structure, perfect outline, thunder, erosion and adding resistance.
3). Strong and reasonable structure with mechanical sealing structure, can be opened after sealing and cab be reused.
4). Well water and dust proof, unique grounding device to ensure the sealing performance, convenient for installation.
5). The splice closure has a wide application range, with good sealing performance, easy installation, produced with high strength
engineering plastic housing, with anti-aging, corrosion resistance, high temperature and high mechanical strength and so on.
Technique Performance:
1. External size 480x250x1U, 2U,
2. Fiber capacity from 12 cores to 48 cores
3. Insertion loss: <0.3dB
4. Return loss: PC< 40 dB, UPC<50dB, APC< 60dB
5. Winding radius ≥40mm
6. Working temperature -25°C~+45°C
7. Atmosphere pressure 70~106Kpa
8. Insulated Resistance 2×10MΩ/500V(DC)W
9. Voltage- resistance:Under the effect of 3kv/DC/1min, non-puncture, and no arc-over.
Specification:
| Name | Desktop 12 Ports SC Pigtail Fiber Optic Patch Panel |
| Type | Desktop |
| Accessories | 12 pcs sc pigtail, 12pcs sm sc adapters |
| Dimensions | 265*130*40mm(Length*Depth*Height) |
| Iron Plate Thickness | 0.6mm |
| Weight | 0.6kg |
| Color | Black paint |
| Material | Cold-rolled plate |
| Storage/Working Temperature | -40~+85℃ |
Application:
1. Widely used in FTTH access network
2. Telecommunication networks
3. CATV networks, LAN Network
4. Data communications networks
5. Local area networks
6. Active device termination
12端口光纖配線架機架安裝式光纖接線盒
描述：
分光器封閉件為光纜的熔接和連接提供了空間和保護。光纖封閉件屬于光纖熔接段系統的容納區。它被廣泛應用于光纖的連接中，起到密封，保護，光纖連接器頭的安裝和存放的作用。
特征：
1）。高質量的PC，ABS，PPR材料可選，可以確保惡劣的條件，例如振動，沖擊，拉力電纜變形
和強烈的溫度變化。
2）。堅固的結構，完美的輪廓，雷聲，侵蝕和增加阻力。
3）。具有機械密封結構的堅固合理的結構，密封后可以打開，駕駛室可以重復使用。
4）。井眼防水防塵，獨特的接地裝置，確保密封性能，安裝方便。
5）。接頭盒適用范圍廣，密封性能好，安裝方便，采用高強度
工程塑料外殼制造，具有抗老化，耐腐蝕，耐高溫，機械強度高等特點。
技術性能：
1.外部尺寸480x250x1U，2U，
2.從12芯光纖容量到48個內核
3.插入損耗：<0.3分貝
4.回波損耗：PC <40分貝，UPC <50分貝，APC <60分貝
5.卷繞半徑≥40mm
6 。工作溫度-25° C?+ 45°C
7.大氣壓力70?106Kpa
8.絕緣電阻2×10MΩ/ 500V（DC）W
9.耐電壓：在3kv / DC / 1min的作用下，非刺破，無飛弧。
規格：
| 姓名 | 臺式機12端口SC尾纖光纖配線架 |
| 類型 | 桌面 |
| 配件 | 12個SC尾纖，12個SM SC適配器 |
| 方面 | 265 * 130 * 40mm（長*深*高） |
| 鐵板厚度 | 0.6毫米 |
| 重量 | 0.6公斤 |
| 顏色 | 黑漆 |
| 材料 | 冷軋板 |
| 儲存/工作溫度 | -40?+ 85℃ |
應用：
1.廣泛用于FTTH接入網絡
2.電信網絡
3. CATV網絡，LAN網絡
4.數據通信網絡
5.局域網
6.有源設備終端
